defQuantityFunction



The defQuantityFunction form defines a function that maps a tuple of objects to a quantity. In addition to being globally defined via defQuantityFunction, quantity functions may also be defined within model fragment and entity definitions in the :quantities clause (See section , page ).


Figure: Quantity functions are defined with the defQuantityFunction form. Quantity functions associate time dependent quantities with the objects that they describe.

 (defQuantityFunction QF name (x ...x)

		  [ :=> implication asentence]

		  [ :dimension dimension expression ]

		  [ :non-numeric non-numeric? ]

		  [ :piecewise-continuous piecewise-continuous? ]

		  [ :step-quantity step-quantity? ]

		  [ :count-quantity count-quantity? ])

The QF name is a function constant naming an n-ary function that returns a time-dependent quantity. The x ... x are logical variables.

:=>

The implication asentence is a logical sentence that mentions the variables x. It may be used to place restrictions on the values that the time dependent quantity may take on, or assert things, such as type information, about the x. The translations required to make time explicit (See section , page ) are performed on the implication asentence.

:dimension

The dimension expression is a dimension expression (See section , page  for the complete syntax). It specifies the dimension of the quantities returned by the quantity function.

:non-numeric

If boolean non-numeric? is true, then the quantities returned by the quantity function are non-numeric valued, otherwise they are numeric.

:piecewise-continuous

If boolean piecewise-continuous? is true, then the quantities returned by the quantity function are piecewise-continuous.

:step-quantity

If boolean step-quantity? is true, then the quantities returned by the quantity function are step-quantities.

:count-quantity

If boolean count-quantity? is true, then the quantities returned by the quantity function are count-quantities. A count quantity is dimensionless.

The semantics of the form is defined by the following axiom:

where type is determined by the boolean keywords and defaults to everywhere-continuous.
