Semantics

After performing the syntactic substitutions (See section gif, page gif) and the translations required to make time dependence explicit (See section gif, page gif), the semantics of the model fragment form may be defined after making some preliminary definitions:

A literal is time dependent if its relation constant names a time dependent relation or it contains a time dependent term. A term is time dependent if it has a function constant that names a time dependent function or a quantity function, or if it contains a time dependent term.

A literal is time independent if it is not time dependent.

The conditions and consequences may be separated into their time-dependent and time-independent portions.

Let temporal conditions be the time dependent conditions in conditions, and atemporal conditions be the time independent ones. Let temporal consequences be the time dependent consequences in consequences, and atemporal consequences be the time independent ones.

We can divide the axioms into four portions:

  1. Establish the definitional properties and atemporal consequences of an instance.
  2. Define when an object is an active instance of name.
  3. Establish the temporal consequences of an active instance of name.
  4. Establish whether an instance of name with a given set of participants logically exists.

If an object is an instance of name, the following definitional axiom defines invariant properties of the object:

   eqnarray515

where attribute axiom is tex2html_wrap_inline2404 when type is provided, quantity axiom is the axiom implied by the quantity function definition for quantity, and the participant axiom is tex2html_wrap_inline2414 when participant type is provided.

The following axiom defines when an instance of name is active:

equation549

That is, m is an active instance of name exactly when m is an instance of name (this ensures that its participants are defined and its atemporal conditions are satisfied), it is an active instance of each of its superclasses, and its temporal conditions are satisfied.

tex2html_wrap2438 We provide an axiom that specifies that the temporal consequences hold whenever an instance is active:

eqnarray564

tex2html_wrap2440 If there are participants or conditions, then these define both necessary and sufficient conditions for an object to be an instance of name. The form of the axiom depends on whether or not name has any superclasses. If there are explicit superclasses, then any object that is an instance of the superclasses and also satisfies the additional restrictions is an instance of name. If name does not have any explicit superclasses, then the existence of participants that satisfy the conditions is sufficient to imply the existence of an instance.

If there are neither participants nor conditions, then there is no axiom defined to infer that an object is an instance of name. It is, of course, possible for this to be inferred by user specified axioms via defRelation or other model fragment definitions. When there are no participants or conditions, the defModelFragment form is equivalent to the defEntity form.

If name has explicit superclasses (i.e. the :subclass-of clause is not empty), the following axiom is used:

equation583

If there are no explicit superclasses, but there are either participants or conditions, then the following axiom is used:

equation596

tex2html_wrap2442
